ABB / General Electric TEY160 Miniature Circuit Breaker
- 60A
- 1 Pole
- Bolt-On
ABB / General Electric
TEY160
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
TEY160
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TEY160 - 60A 1 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
30A 1 Pole Miniature Circuit Breaker
25A 1 Pole Miniature Circuit Breaker
100A 1 Pole Miniature Circuit Breaker
Description
Part of the robust Q-Line family, this 60-amp single-pole breaker is built for commercial and industrial power management. It mounts into GE A-Series panelboards, offering a steadfast bolt-on connection that resists vibration. Rated for 65kAIC at 120VAC and 14kAIC at 277VAC, the unit delivers high interrupting capacity for demanding environments. Standard features include a quick-make/quick-break mechanism and HACR rating, ensuring reliable operation across diverse electrical systems.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEY160 |
| Series | TEY |
| Amperage | 60A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 277VAC, 125VDC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 14kA @ 240VAC, 14kA @ 277VAC, 10kA @ 125VDC, 14kA @ 120/240VAC |
| Frame Type | TEY |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Panelboards |
| Wire Gauge | 10-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break |
Product FAQs
5 answersWhat panelboards are compatible with the TEY160 circuit breaker?
The TEY160 is designed specifically for use in GE A-Series panelboards. It features a bolt-on connection and requires a 1-inch space per pole.
Are there higher interrupting rating alternatives to the TEY160?
Yes. While the standard TEY160 is rated for 14kAIC at 277VAC, the TEY frame is available in higher interrupting tiers. Alternatives include the TEYF (18kAIC), TEYD (25kAIC), TEYH (35kAIC), and TEYL (65kAIC) series, which share the same physical footprint for GE A-Series panelboards.
What are the lug torque specifications for the TEY160?
For the factory-installed lugs on the TEY160, the tightening torque depends on the wire size used. Torque to 35 in-lb for #10 AWG, 40 in-lb for #8 AWG, and 45 in-lb for #6 to #4 AWG copper or aluminum wire.
Is the TEY160 circuit breaker HACR rated?
Yes, the TEY160 carries an HACR rating, making it suitable for use with heating, air conditioning, and refrigeration equipment. It is also HID (High-Intensity Discharge) rated for lighting circuits.
Can the TEY160 be used in DC voltage applications?
Yes, the TEY160 is rated for DC applications up to 125VDC, with an interrupting rating of 10kAIC at that voltage.
