ABB / General Electric THQL1130ST1 Miniature Circuit Breaker
- 30A
- 1 Pole
- Plug-On
ABB / General Electric
THQL1130ST1
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
THQL1130ST1
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQL1130ST1 - 30A 1 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTHQL2130ST1
30A 2 Pole Miniature Circuit Breaker
ABB / General ElectricTHQL32030ST1
30A 3 Pole Miniature Circuit Breaker
ABB / General ElectricTHQB1130ST1
30A 1 Pole Miniature Circuit Breaker
Description
The THQL1130ST1 is a 30-amp, single-pole miniature circuit breaker designed for commercial power distribution. It provides reliable thermal-magnetic protection with a 10kAIC rating at 120VAC. This plug-on breaker mounts into GE Q-Line and PowerMark Gold load centers. It features box lug terminals accepting 14-8 AWG copper or 12-8 AWG aluminum wiring. A factory-installed 120VAC shunt trip allows remote tripping, ideal for emergency stop systems. The unit is HACR rated for HVAC applications.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQL1130ST1 |
| Series | THQL |
| Amperage | 30A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Frame Type | THQL |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | GE Q-Line Load Centers, GE PowerMark Gold Load Centers, ABB ReliaHome Load Centers |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Auxiliary Switch, Padlock Attachment |
|---|---|
| Accessories | Shunt Trip (Factory Installed) |
| Standards | UL 489, NEMA AB 1, HACR |
| Approval | UL |
| Temp Rating | 60C to 75C |
| Construction Features | HACR Rated, Quick-Make/Quick-Break |
Product FAQs
5 answersCan I install the THQL1130ST1 in a GE A-Series panelboard?
No. The THQL1130ST1 is a plug-in breaker designed for GE Q-Line, PowerMark Gold, and ABB ReliaHome load centers. GE A-Series panelboards require bolt-on breakers like the THQB1130ST1.
What does the "ST1" suffix indicate on this THQL breaker?
The ST1 suffix indicates that this breaker includes a factory-installed 120VAC shunt trip. This allows the breaker to be tripped remotely, which is commonly used for emergency stop systems or remote load shedding.
Is the THQL1130ST1 suitable for use with heating and air conditioning equipment?
Yes, this breaker is HACR rated, making it suitable for use with HVAC applications that require a 30A, 1-pole circuit.
Why might my THQL1130ST1 breaker arrive with ABB branding instead of GE?
ABB acquired GE Industrial Solutions in 2018. As a result, Q-Line breakers like the THQL1130ST1 may feature either ABB or GE branding, but they are identical in form, fit, and function.
Does the THQL1130ST1 provide GFCI or AFCI protection?
No, this is a standard thermal-magnetic breaker equipped with a shunt trip. It provides standard overcurrent and short-circuit protection, but does not include ground fault or arc fault circuitry.
