Siemens 3VA4150-6ED14-0AA0 Molded Case Circuit Breaker
- 50A
- 1 Pole
- Panel Mount
Siemens
3VA4150-6ED14-0AA0
Molded Case Circuit Breaker
Brand
Siemens
SKU
3VA4150-6ED14-0AA0
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens 3VA4150-6ED14-0AA0 - 50A 1 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
30A 1 Pole Molded Case Circuit Breaker
25A 1 Pole Molded Case Circuit Breaker
20A 1 Pole Molded Case Circuit Breaker
Description
Part of the SENTRON 3VA4 series, this 50-amp single-pole molded case circuit breaker provides fixed thermal and magnetic trip functions for commercial and industrial applications. It mounts into Siemens P1, P2, and P3 panelboards and switchboards, serving as a modern upgrade that replaces legacy ED61B050 units when used with the proper mounting kit. Featuring a robust 150kA interrupting capacity at 120VAC, this HACR and HID-rated component ensures exceptional current-limiting performance.Specifications
| Brand | Siemens |
|---|---|
| Series | 3VA4 |
| Amperage | 50A |
| Poles | 1 |
| Mounting Style | Panel Mount |
| Voltage | 120VAC, 277VAC, 125VDC, 347VAC |
| Phase | 1 |
| AIC Rating | 150kA @ 120VAC, 65kA @ 277VAC, 30kA @ 125VDC, 25kA @ 347VAC |
| Frame Type | 3VA41 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 8 AWG - 3/0 AWG (Cu/Al) |
| Max Wire | 3/0 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, High Interrupting Capacity |
Product FAQs
6 answersWhat panelboards are compatible with the 3VA4150-6ED14-0AA0?
This breaker is designed for installation in Siemens P1, P2, and P3 panelboards, as well as Siemens switchboards.
What legacy Siemens breaker does this model replace?
This specific high-interrupting Class H 3VA4 breaker serves as a direct replacement for legacy Siemens HEAB series circuit breakers.
Can this circuit breaker be reverse fed?
Yes, Siemens 3VA4 molded case circuit breakers are reverse-feed capable, providing flexibility for various installation requirements.
Is the trip unit on this breaker adjustable?
No, it features a TM210 thermal-magnetic trip unit with fixed thermal and fixed magnetic (FTFM) settings for long-time and instantaneous (LI) protection.
Does this breaker come with lugs installed?
Yes, the 0AA0 suffix in the catalog number indicates that it comes factory-equipped with standard load-side lug terminals.
Is this breaker suitable for HVAC applications?
Yes, it is HACR rated, meaning it is approved for use with heating, air conditioning, and refrigeration equipment.
