Siemens ED62B035 Molded Case Circuit Breaker
- 35A
- 2 Pole
- Bolt-On
Siemens
ED62B035
Molded Case Circuit Breaker
Brand
Siemens
SKU
ED62B035
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens ED62B035 - 35A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens ED62B035 - 35A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED62B035 |
| Series | ED6 |
| Amperage | 35A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Sold out
Quantity
Siemens ED62B035 - 35A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED62B035-R |
| Series | ED6 |
| Amperage | 35A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
70A 2 Pole Molded Case Circuit Breaker
90A 2 Pole Molded Case Circuit Breaker
35A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial power distribution, the Siemens ED62B035 delivers robust 35A overcurrent protection. This Sentron series molded case circuit breaker utilizes a non-interchangeable thermal-magnetic trip unit to safeguard electrical systems. The unit mounts into Siemens P1, P2, and P3 panelboards, switchboards, and motor control centers. It includes load side lugs accepting 10-1/0 AWG wire. Rated 65kAIC at 240V, this ED frame breaker is HACR rated and reverse feed capable.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED62B035 |
| Series | ED6 |
| Amperage | 35A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhich Siemens panelboards are compatible with the ED62B035 circuit breaker?
This bolt-on breaker is designed for use in Siemens Sentron Series P1, P2, and P3 panelboards, as well as compatible switchboards and motor control centers.
What is the difference between Siemens ED4 and ED6 series breakers?
The primary difference is the maximum voltage rating. ED4 breakers are rated up to 480VAC, while ED6 breakers like the ED62B035 are rated for up to 600VAC. Both share the same physical ED frame footprint and mounting style.
Can the ED62B035 be used in DC voltage applications?
Yes, this breaker is rated for DC applications up to 250VDC, providing an interrupting capacity of 30kAIC at that voltage.
Are the load lugs included with this ED frame breaker?
Yes, it comes standard with load side lugs that accept 10 to 1/0 AWG copper or aluminum wire.
Can I adjust the trip settings on the ED62B035?
No, this breaker features a fixed thermal and fixed magnetic trip unit. It does not offer adjustable long time or instantaneous settings.
Is this breaker suitable for DIN rail mounting?
No, the ED62B035 is a bolt-on molded case circuit breaker designed specifically for panelboard and switchboard chassis mounting, not for DIN rail applications.
