Siemens EF3A010 Motor Circuit Protector
- 10A
- 3 Pole
- Bolt-On
Siemens
EF3A010
Motor Circuit Protector
Brand
Siemens
SKU
EF3A010
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens EF3A010 - 10A 3 Pole Motor Circuit Protector
Re-Certified
Quantity
Similar Items
25A 3 Pole Motor Circuit Protector
30A 3 Pole Motor Circuit Protector
100A 3 Pole Motor Circuit Protector
Description
Part of the legacy E-Frame series, the Siemens EF3A010 is a 3-pole motor circuit protector built for industrial control applications. It delivers instantaneous magnetic-only protection to prevent equipment damage. This 10A bolt-on breaker mounts into older Siemens and I-T-E FC-1 panelboards or FC-20 switchboards. For modern upgrades, it is replaced by the ED63A010. Featuring an adjustable trip range of 27-84A, it allows precise coordination with motor starters.Specifications
| Brand | Siemens |
|---|---|
| Part Number | EF3A010-R |
| Series | EF |
| Amperage | 10A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Amperage Range | 27-84A |
|---|
| Frame Type | EF |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens / I-T-E Panelboards, FC-1 Panelboards, FC-20 Switchboards |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Motor Circuit Protector, Non-Interchangeable Trip |
