Siemens FXD62B175 Molded Case Circuit Breaker
- 175A
- 2 Pole
- Unit Mount
Siemens
FXD62B175
Molded Case Circuit Breaker
Brand
Siemens
SKU
FXD62B175
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens FXD62B175 - 175A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens FXD62B175 - 175A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Series | FXD6 |
| Amperage | 175A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 22kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | FXD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Sentron Switchboards, Motor Control Centers, Sentron Enclosures |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | No Lugs Installed |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Quantity
Siemens FXD62B175 - 175A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Series | FXD6 |
| Amperage | 175A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 22kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | FXD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Sentron Switchboards, Motor Control Centers, Sentron Enclosures |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | No Lugs Installed |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
200A 2 Pole Molded Case Circuit Breaker
200A 2 Pole Molded Case Circuit Breaker
150A 2 Pole Molded Case Circuit Breaker
Description
Built for commercial and industrial applications, the Siemens FXD62B175 delivers 2-pole, 175A protection within the Sentron FD frame family. It provides fixed thermal and adjustable magnetic (LI) trip functions for robust circuit protection. Rated at 35 kAIC at 480VAC, this unit-mount breaker is HACR rated and suitable for reverse feed applications. It installs into Siemens P1, P2, and P3 panelboards, motor control centers, and Sentron enclosures. Supplied with no lugs installed.Specifications
| Brand | Siemens |
|---|---|
| Series | FXD6 |
| Amperage | 175A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 22kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | FXD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Sentron Switchboards, Motor Control Centers, Sentron Enclosures |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | No Lugs Installed |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
7 answersDoes the FXD62B175 come with line and load lugs installed?
No, the standard FXD62B175 is supplied without lugs. If you need factory-installed lugs, look for catalog number FXD62B175L. For field installation, the standard lug kit is TA1FD350A, which accepts 6 AWG to 350 kcmil copper or 4 AWG to 350 kcmil aluminum wire.
What is the magnetic trip adjustment range for this 175A breaker?
The FXD62B175 features a fixed thermal and adjustable magnetic trip unit. The instantaneous magnetic trip can be adjusted from 900A to 2000A.
Which Siemens panels and enclosures are compatible with the FXD62B175?
This FD-frame breaker is designed for use in Siemens P1, P2, and P3 panelboards, Sentron switchboards, motor control centers, and Sentron enclosures.
Is the trip unit on the FXD62B175 interchangeable?
No, this breaker features a non-interchangeable thermal-magnetic trip unit. The entire breaker must be replaced if a different trip rating is required.
How does the FXD62B175 differ from the HFD62B175?
Both are 175A, 2-pole FD-frame breakers, but they have different interrupting ratings. The FXD62B175 is the standard-interrupting version rated at 35kAIC at 480V, while the HFD62B175 is the high-interrupting version rated at 65kAIC at 480V.
Can the FXD62B175 be reverse fed?
Yes. Because it features a non-interchangeable trip unit, the FXD62B175 is UL listed for reverse feed applications.
What type of fault protection does the FXD62B175 provide?
It provides thermal-magnetic protection with a Long-Time (L) function for standard overload protection and an Instantaneous (I) function for short-circuit protection.
