Siemens FXD62B225L Molded Case Circuit Breaker
- 225A
- 2 Pole
- Unit Mount
Siemens
FXD62B225L
Molded Case Circuit Breaker
Brand
Siemens
SKU
FXD62B225L
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens FXD62B225L - 225A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
250A 2 Pole Molded Case Circuit Breaker
175A 2 Pole Molded Case Circuit Breaker
125A 2 Pole Molded Case Circuit Breaker
Description
Featuring factory-included lugs, the FXD62B225L functions as a 2-pole, 225A MCCB. It provides reliable long-time and instantaneous (LI) thermal-magnetic protection for commercial and industrial systems. This unit-mount breaker fits Siemens P1, P2, and P3 panelboards. It serves as an exact replacement for legacy F-Frame breakers and is superseded by the 3VA52 series. Rated for 35kAIC at 480VAC, it includes an adjustable magnetic trip, HACR rating, and reverse feed capability.Specifications
| Brand | Siemens |
|---|---|
| Part Number | FXD62B225L |
| Series | FXD6 |
| Amperage | 225A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 22kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | FD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 6 AWG - 350 kcmil |
| Max Wire | 350 kcmil |
| Min Wire | 6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line & Load Lugs (TA1FD350A) |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhat does the L suffix in the FXD62B225L catalog number indicate?
The L signifies that the circuit breaker includes factory-installed line and load lugs.
Which lug kit is standard for this circuit breaker?
The standard lug kit is the Siemens TA1FD350A, which accepts aluminum or copper conductors from 6 AWG to 350 kcmil.
What is the modern replacement series for this breaker?
The FXD62B225L is superseded by the newer Siemens 3VA52 series of molded case circuit breakers.
Can the FXD62B225L replace older F-Frame breakers?
Yes, this unit serves as a direct, exact replacement for legacy Siemens F-Frame circuit breakers with matching specifications.
Is this circuit breaker suitable for reverse feed applications?
Yes, the FXD62B225L is UL listed for reverse feed installations.
Is this breaker HACR rated?
Yes, it carries an HACR rating, making it suitable for heating, air conditioning, and refrigeration equipment protection.
