ABB / General Electric TQD32150 Molded Case Circuit Breaker
- 150A
- 3 Pole
- Bolt-On
ABB / General Electric
TQD32150
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TQD32150
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TQD32150 - 150A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric TQD32150 - 150A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32150 |
| Series | TQD |
| Amperage | 150A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Reverse Feed, Non-Interchangeable Trip |
Quantity
ABB / General Electric TQD32150 - 150A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32150-R |
| Series | TQD |
| Amperage | 150A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Reverse Feed, Non-Interchangeable Trip |
Similar Items
ABB / General ElectricTQD32125
125A 3 Pole Molded Case Circuit Breaker
3 Pole Circuit Breaker
ABB / General ElectricTQD32100
100A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial power distribution, this 150A three-pole breaker utilizes fixed thermal and magnetic trip elements. The bolt-on configuration ensures a secure connection within GE A-Series and Spectra Series panelboards. When transitioning to newer infrastructure, this component is replaced by the ABB Formula A2 series using an appropriate retrofit kit. Providing a 10kA interrupting capacity at 240VAC, it features reverse feed capability, load side lugs, and a standard HACR rating.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32150 |
| Series | TQD |
| Amperage | 150A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
5 answersWhich panelboards accept the TQD32150 circuit breaker?
This breaker is engineered for GE A-Series and Spectra Series panelboards. The panel interior must be properly configured for Q-Line bolt-on branch or main breakers.
What trip adjustments are available on this model?
The TQD32150 features a thermal magnetic trip unit with fixed Long-Time and Instantaneous protection. Neither the overload nor the short circuit parameters are field adjustable.
Is there a direct alternative if the system requires an interrupting rating higher than 10kAIC?
Yes. If the available fault current exceeds the 10kAIC at 240V rating of this breaker, the THQD32150 is the appropriate upgrade. It shares the exact physical footprint and bolt-on connection but provides a 22kAIC rating.
What is the conductor capacity for the factory lugs?
The factory installed mechanical lugs accept copper or aluminum conductors ranging from 4 AWG to 300 kcmil. Installers must reference the breaker faceplate for specific lug torque values during termination.
Can this molded case breaker serve as a main breaker?
Yes, it is suitable for both main breaker and branch circuit applications in commercial distribution systems. The host panelboard and mounting hardware must be rated to support a 150A bolt-on main.
