ABB / General Electric TQD32225 Molded Case Circuit Breaker
- 225A
- 3 Pole
- Bolt-On
ABB / General Electric
TQD32225
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TQD32225
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TQD32225 - 225A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric TQD32225 - 225A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32225 |
| Series | TQD |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 120VAC, 10kA @ 240VAC, 10kA @ 120/240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Shunt Trip, Undervoltage Release, Lug Kits |
|---|---|
| Accessories | Load Side Lugs (TCAL25) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip, HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Quantity
ABB / General Electric TQD32225 - 225A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32225-R |
| Series | TQD |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 120VAC, 10kA @ 240VAC, 10kA @ 120/240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Shunt Trip, Undervoltage Release, Lug Kits |
|---|---|
| Accessories | Load Side Lugs (TCAL25) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip, HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
ABB / General ElectricTQD32175
175A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTQD32150
150A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTQD32125
125A 3 Pole Molded Case Circuit Breaker
Description
Built for commercial and industrial applications, the TQD32225 serves as a 3-pole molded case circuit breaker within GE's Q-Line series. It provides reliable thermal-magnetic protection with fixed long-time and instantaneous (LI) trip functions. This bolt-on MCCB installs into GE A-Series and Spectra Series panelboards. Rated for 225 amps and 240VAC, it features a 10kAIC interrupting capacity. It functions as an exact replacement for older installations, replaced by the ABB Formula A2.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32225 |
| Series | TQD |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 120VAC, 10kA @ 240VAC, 10kA @ 120/240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Shunt Trip, Undervoltage Release, Lug Kits |
|---|---|
| Accessories | Load Side Lugs (TCAL25) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip, HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
5 answersHow are the line and load connections configured on the TQD32225?
This unit features a bolt-on line side that mounts directly to the panelboard bus. The load side includes factory-installed lugs that accept 4 AWG to 300 kcmil copper or aluminum conductors.
How does the TQD32225 compare to the THQD32225?
Both breakers share the same physical frame and fit the same GE panelboards, but they have different short-circuit interrupting ratings. The TQD32225 is rated at 10kAIC at 240V, while the THQD32225 is rated higher at 22kAIC.
What is the continuous current rating standard for this breaker?
It is a standard 80 percent rated circuit breaker. For continuous loads lasting three hours or more, the applied current should not exceed 180 amps, which is 80 percent of its nominal 225-amp rating.
Are ABB and General Electric TQD breakers completely interchangeable?
Yes. Since ABB acquired the GE Industrial Solutions division, the TQD product line remains identical in form, fit, and function. An ABB unit will directly replace a legacy GE model in existing panels without modifications.
Is this breaker HACR rated for mechanical loads?
Yes. It carries a Heating, Air Conditioning, and Refrigeration (HACR) rating, meaning it has been tested and approved to handle the unique inrush currents associated with commercial HVAC compressor motors.
