Federal Pacific NE237025 Molded Case Circuit Breaker
- 25A
- 3 Pole
- Bolt-On
Federal Pacific
NE237025
Molded Case Circuit Breaker
Brand
Federal Pacific
SKU
NE237025
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Federal Pacific NE237025 - 25A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
30A 3 Pole Molded Case Circuit Breaker
30A 3 Pole Molded Case Circuit Breaker
20A 3 Pole Molded Case Circuit Breaker
Description
A drop-in replacement for aging commercial systems, the Federal Pacific NE237025 is a 3-pole, 25A molded case circuit breaker. It provides essential thermal-magnetic protection for industrial applications requiring a 240VAC rating. Designed for exact compatibility, this bolt-on MCCB mounts into legacy Federal Pacific NE panelboards. It eliminates the need for retrofits or adapters, ensuring a seamless restoration of service. Rated at 18 kAIC at 240VAC, it features a non-interchangeable trip.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NE237025 |
| Series | NE |
| Amperage | 25A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 5kA @ 250VDC |
| Frame Type | NE-7 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Federal Pacific NE Panelboards |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | NEMA AB-1, UL 489 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | Non-Interchangeable Trip, Reverse Feed |
Product FAQs
4 answersIs the NE237025 a residential Stab-Lok breaker?
No. The NE237025 is an NE-frame molded case circuit breaker designed for commercial and industrial applications. It uses a bolt-on connection and does not feature the residential Stab-Lok push-on design.
Can the NE237025 be used in direct current systems?
Yes, this breaker is rated for 250VDC applications and provides an interrupting capacity of 5kAIC for direct current systems, in addition to its standard alternating current ratings.
Which panelboards accept the NE237025 circuit breaker?
This breaker is designed specifically for installation in legacy Federal Pacific NE series panelboards. It requires a bolt-on connection and will not fit in standard plug-on load centers.
Does the NE237025 feature an adjustable trip setting?
No, this breaker is equipped with a fixed thermal and fixed magnetic trip unit. It provides standard long-time and instantaneous protection but cannot be field-adjusted for different trip curves.
