Square D FY14015A Molded Case Circuit Breaker
- 15A
- 1 Pole
- I-Line
Square D
FY14015A
Molded Case Circuit Breaker
Brand
Square D
SKU
FY14015A
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D FY14015A - 15A 1 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Sold out
Quantity
Square D FY14015A - 15A 1 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | FY14015A |
| Series | FY |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | I-Line |
| Voltage | 277VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 18kA @ 277VAC, 10kA @ 125VDC |
| Frame Type | FY |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | 14-4 AWG (Cu), 12-4 AWG (Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Handle Padlock Attachment |
|---|---|
| Accessories | Phase A Connection (Factory Configured) |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated, Visual Trip Indicator |
Quantity
Square D FY14015A - 15A 1 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | FY14015A-R |
| Series | FY |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | I-Line |
| Voltage | 277VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 18kA @ 277VAC, 10kA @ 125VDC |
| Frame Type | FY |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | 14-4 AWG (Cu), 12-4 AWG (Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Handle Padlock Attachment |
|---|---|
| Accessories | Phase A Connection (Factory Configured) |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated, Visual Trip Indicator |
Similar Items
20A 1 Pole Molded Case Circuit Breaker
20A 1 Pole Molded Case Circuit Breaker
15A 1 Pole Molded Case Circuit Breaker
Description
Built for heavy-duty commercial environments, this 15A molded case circuit breaker provides robust long-time and instantaneous trip functions. This legacy F-Frame unit mounts into Square D I-Line panelboards using a secure plug-in connection. Facilities looking to upgrade can substitute this model with the newer BDA140151 breaker. Delivering an 18kAIC rating at 277VAC, it features a factory-configured Phase A connection. The Visi-Trip indicator allows personnel to quickly spot tripped circuits.Specifications
| Brand | Square D |
|---|---|
| Part Number | FY14015A-R |
| Series | FY |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | I-Line |
| Voltage | 277VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 18kA @ 277VAC, 10kA @ 125VDC |
| Frame Type | FY |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | 14-4 AWG (Cu), 12-4 AWG (Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Handle Padlock Attachment |
|---|---|
| Accessories | Phase A Connection (Factory Configured) |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated, Visual Trip Indicator |
Product FAQs
5 answersHow does the FY14015A install into a panelboard?
It utilizes an I-Line plug-on connection, which allows the breaker to engage directly with the busbar in Square D I-Line panelboards and switchboards without the need for bolt-on hardware.
What does the 'A' suffix in the FY14015A catalog number indicate?
The 'A' suffix denotes that this 1-pole breaker is factory-configured specifically for an A-phase connection on the I-Line busbar.
Is the Square D FY14015A still manufactured, or is there a direct replacement?
The FY frame is a legacy F-Frame breaker. For new installations or upgrades, it is commonly replaced by the modern PowerPact B-frame equivalent, catalog number BDA140151, which shares the same 15A rating, I-Line mounting, and A-phase configuration.
Is the FY14015A suitable for direct current (DC) systems?
Yes, in addition to its standard AC ratings, this thermal-magnetic breaker is certified for DC applications up to 125VDC, providing a 10kA interrupting capacity for DC control or distribution circuits.
Are the trip settings on the FY14015A adjustable?
No, this breaker features a fixed thermal-magnetic trip unit. Both the long-time overload and instantaneous short-circuit trip functions are factory-set and cannot be adjusted in the field.
