Square D HOM115 Miniature Circuit Breaker
- 15A
- 1 Pole
- Plug-On
Square D
HOM115
Miniature Circuit Breaker
Brand
Square D
SKU
HOM115
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D HOM115 - 15A 1 Pole Miniature Circuit Breaker
New
Quantity
Quantity
Square D HOM115 - 15A 1 Pole Miniature Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | HOM115 |
| Series | HOM |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | HOM |
|---|---|
| Terminal Type | Screw/Clamp Terminal |
| For Use With | Homeline Load Centers |
| Wire Gauge | 14-8 AWG (Al/Cu) or (2) 14-10 AWG (Cu) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated |
Sold out
Quantity
Square D HOM115 - 15A 1 Pole Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | HOM115-R |
| Series | HOM |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | HOM |
|---|---|
| Terminal Type | Screw/Clamp Terminal |
| For Use With | Homeline Load Centers |
| Wire Gauge | 14-8 AWG (Al/Cu) or (2) 14-10 AWG (Cu) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated |
Similar Items
25A 1 Pole Miniature Circuit Breaker
30A 1 Pole Miniature Circuit Breaker
40A 1 Pole Miniature Circuit Breaker
Description
Residential electrical systems require dependable overcurrent defense, which this 15A single-pole breaker delivers. It mounts into Square D Homeline load centers using a simple plug-on mechanism, making it ideal for standard household lighting and outlet circuits. The unit carries a Switching Duty (SWD) rating, allowing it to safely control fluorescent lighting loads on a regular basis. With a 10kAIC rating at 120/240V, it meets standard residential requirements and accepts 14-8 AWG wiring.Specifications
| Brand | Square D |
|---|---|
| Part Number | HOM115 |
| Series | HOM |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | HOM |
|---|---|
| Terminal Type | Screw/Clamp Terminal |
| For Use With | Homeline Load Centers |
| Wire Gauge | 14-8 AWG (Al/Cu) or (2) 14-10 AWG (Cu) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated |
Product FAQs
7 answersCan I install the HOM115 breaker in a Square D QO or Siemens load center?
No. The HOM115 is exclusively designed for Square D Homeline load centers. It utilizes a 1-inch format and a specific bus bar mounting style that will not seat properly in QO panels, Siemens panels, or other incompatible brands. Mixing breaker brands or series violates UL listings.
What is the recommended terminal torque specification for the HOM115 circuit breaker?
The recommended tightening torque for the HOM115 screw clamp terminal is 35 lb-in (4.0 N-m). Always verify the torque specification printed directly on the side of the breaker before finalizing installation.
Does the HOM115 terminal accept more than one wire?
Yes, the clamp terminal on the HOM115 is rated to accept dual copper wires. You can insert up to two 14-10 AWG copper conductors into the single terminal lug. If using aluminum wire, it only accepts a single 14-8 AWG conductor.
What is the tandem equivalent for this 15-amp Homeline breaker?
The tandem version of this breaker is catalog number HOMT1515. It provides two independent 15-amp circuits while occupying the exact same single 1-inch panel space as the standard HOM115.
Are there AFCI and GFCI versions of the HOM115 available?
Yes. For branch circuits requiring specialized protection, you can use the HOM115CAFI (Combination Arc Fault), HOM115GFI (Ground Fault), or the HOM115DF (Dual Function AFCI and GFCI). Newer panels may require the plug-on neutral versions, such as the HOM115PCAFI.
Is the HOM115 breaker SWD and HACR rated?
Yes. The HOM115 is Switching Duty (SWD) rated, meaning it can safely be used to switch 120-volt fluorescent lighting loads on and off on a regular basis. It is also HACR rated for use with compatible heating, air conditioning, and refrigeration equipment.
Does the standard HOM115 require a neutral connection?
No. As a standard thermal-magnetic breaker, the HOM115 does not require a neutral wire connection to operate. Neutral pigtails or plug-on neutral clips are only found on the AFCI, GFCI, and dual-function Homeline variants.
